(2) Detaching and refitting the paper feed roller unit

Procedure

1. Remove the retard roller unit (see page

1-5-12).

2. Turn forward the lever of the feed pin to

release the lock.

3. Slide the feed pin.

Figure 1-5-20

Feed pin

Lever
