2PS/2PT
1-1-4
(2) Machine (rear side)
Figure 1-1-2
20
19
18
21
16
15
17
23
25
22
24
15. Rear cover
16. Rear cover lever
17. IF cover
18. Memory cover
19. Power cord cover
20. Paper conveying unit
21. Power cord connector
22. Network interface connector
23. USB interface connector
24. USB memory slot
25. Interface slot
