2PS/2PT
1-2-10
1-2-3 Installing the expansion memory (option)
Procedure
1. Turn off the main power switch.
Caution: Do not insert or remove
expansion memory while machine
power is on.
Doing so may cause damage to the
machine and the expansion memory.
2. Remove the memory cover.
Figure 1-2-15
3. Release the hook and then open the
bracket.
Figure 1-2-16
Memory cover
Bracket
Hook
1
2
To Next Page
