2PS/2PT

2-3-10

YC32 1 GND - - Ground

Connected to

laser scanner

unit CY

2NC -- -

3 LONBCN O 0/3.3 V DC APCPWB-C sample/hold signal

4 ENBCN O 0/3.3 V DC APCPWB-C laser enable signal

5 PDCN I 0/3.3 V DC (pulse) Horizontal synchronizing signal

6 GND - - Ground

7NC -- -

8 LONBYN O 0/3.3 V DC APCPWB-Y sample/hold signal

9 ENBYN O 0/3.3 V DC APCPWB-Y laser enable signal

10 PDYN I 0/3.3 V DC (pulse) Horizontal synchronizing signal

11 LSUTHERMY - - Not used

12 POLCLK0 O 0/3.3 V DC (pulse) PM-CY clock signal

13 POLRDYN0 I 0/3.3 V DC PM-CY ready signal

14 POLONN0 O 0/3.3 V DC PM-CY: On/Off

15 GND - - Ground

16 +24V3 O 24 V DC 24 V DC power to PM-CY

YC33

1 GND - - Ground

Connected to

paper feeder

2 OPSCLK O 0/3.3 V DC (pulse) Paper feeder clock signal

3 OPRDYN I 0/3.3 V DC Paper feeder ready signal

4 OPSDI I 0/3.3 V DC (pulse) Paper feeder serial communication data

signal input

5 OPSDO O 0/3.3 V DC (pulse) Paper feeder serial communication data

signal output

6 +3.3V1 O 3.3 V DC 3.3 V DC power to paper feeder

7 GND - - Ground

8 OPSEL0 O 0/3.3 V DC Paper feeder selection signal

9 OPSEL1 O 0/3.3 V DC Paper feeder selection signal

10 OPSEL2 O 0/3.3 V DC Paper feeder selection signal

11 +24V3 O 24 V DC 24 V DC power to paper feeder

Connector Pin Signal I/O Voltage Description
