Utax P-C2660DN Service Manual

2PS/2PT
1-3-17
Service items Description
No. Items Description
Operation panel mask version
Machine serial number
(7) Paper Jam
Log
# Count. Event
Remembers 1 to 16 of
occurrence. If the occur-
rence of the previous
paper jam is less than
16, all of the paper jams
are logged. When the
occurrence excesseds
16, the oldest occur-
rence is removed.
The total page count
at the time of the
paper jam.
Log code (hexadeci-
mal, 5 categories)
(a) Cause of a paper
jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper eject
(a) Cause of paper jam (Hexadecimal)
Refer to P.1-4-2 for paper jem location
0100: Controller sequence error
0105: Registration sensor not detected
0106: Controller sequence error
0110: Top tray open
0111: Rear cover open
0112: Front cover open
0120: Controller sequence error
0121: Controller sequence error
0211: Rear cover open (paper feeder 1)
0212: Rear cover open (paper feeder 2)
0213: Rear cover open (paper feeder 3)
0501: No paper feed from cassette 1
0502: No paper feed from cassette 2
0503: No paper feed from cassette 3
0504: No paper feed from cassette 4
0508: No paper feed from duplex section
0509: No paper feed from MP tray
0511: Multiple sheets in cassette 1
0512: Multiple sheets in cassette 2
0513: Multiple sheets in cassette 3
0514: Multiple sheets in cassette 4
0518: Multiple sheets in duplex section
0519: Multiple sheets in MP tray
1020: MP feed sensor is turned ON
1403: PF feed sensor 1 does not turn ON (Paper feeder 2)
1404: PF feed sensor 1 does not turn ON (Paper feeder 3)
1413: PF feed sensor 1 does not turn OFF (Paper feeder 2)
1414: PF feed sensor 1 does not turn OFF (Paper feeder 3)
1420: PF feed sensor 1 is turned ON
1604: PF feed sensor 2 does not turn ON (Paper feeder 3)
1614: PF feed sensor 2 does not turn OFF (Paper feeder 3)
