Vacon CX Service Manual

OPTIONAL BOARDS Service Manual M4 - M10
29.12.1999 Page 124
10. OPTIONAL BOARDS
Option boards for CX-line frequency converters
*) = Existing label on the board includes two last numbers from the P/N code and seven other
characters. After the beginning of the year 1999 the corresponding OPT board number is also
marked on board.
Est. = Estimated release month
Type of option Status Description P/N code Label
code on
PCB (*
PC code
on copper
side
CX100OPT Available I/O-expander board 1 CB00013 13... PC00013
CX101OPT Available I/O-expander board 2 CB00039 39... PC00041
CX102OPT Available I/O-expander board 3 CB00040 40... PC00013
CX103OPT Available I/O-expander board 4 CB00041 41... PC00041
CX104OPT Available Encoder expander board
for CXS
CB00012 12... PC00012
CX105OPT Est. 09-99 120 V input board CB00079 79... PC00079
CX106OPT Available Analog Expander CX_ CB00017 17... PC00017
CX107OPT Available Fast Encoder CX/CXL/CXS CB00024 24… PC00024
CX108OPT Available I/O-expander board 5 CXS CB00129 129… PC00129
CX200OPT Available Interbus-S bus connection
board
CB00025 25... PC00025
CX201OPT Available Modbus connection board CB00065 65... PC00025
CX202OPT Available Profibus DP connection
board
CB00066 66... PC00066
CX203OPT Available LonWorks connection
boards
CB00067 67... PC00067
CX204OPT Available C-bus connection boards CB00065 65... PC00025
CX206OPT Est. 12-99 Device Net/Encoder
( CH-type )
131… PC00131
CX208OPT Available Device Net CXS–serie
( CH-type )
CB00128 128... PC00128
CX210OPT Available Profibus CXS CB00056 56… PC00056
CX211OPT Est. 12-99 Modbus CXS CB00130 130… PC00056
CX212OPT Available Device Net CXS CB00127 127… PC00128
CX213OPT Est. 12-99 Device Net/Encoder(type) 131… PC00131
