Vacon CX Service Manual

APPENDIXES Service Manual M4 - M10
11.7.2002 Page 140
13.3 Adapter board resistors for M4 - M10 CX/CXL drives
230V P/kW Ict/A Ivt/A Current sensor R1 R2 Rtot N adapter board
M4 1.5 7.0 10.0 LA 55- P/SP1 2000 86.6 402 71.25 4 CB00005
M4 2.2 10.0 13.0 LA 55- P/SP1 2000 68.1 3320 66.73 3 CB00005
M4 3 13.0 16.0 LA 55- P/SP1 2000 100 330 76.74 2 CB00005
M5 4 16.0 22.0 LA 55- P/SP1 2000 127 8200 125.06 1 CB00006
M5 5.5 22.0 30.0 LA 55- P/SP1 2000 100 1000 90.91 1 CB00006
M5 7.5 30.0 43.0 LA 100
P 2000 68.1 3320 66.73 1 CB00009
M6 11 43.0 57.0 LA 205- S 2000 48.7 1000 46.44 1 CB00007
M6 15 57.0 70.0 LA 205- S 2000 42.2 205 35.00 1 CB00007
M6 18.5 70.0 83.0 LA 205- S 2000 33.2 205 28.57 1 CB00007
M6 22 83.0 113.0 LA 205- S 2000 24.3 3320 24.12 1 CB00007
M7 30 113.0 139.0 LA 305- S 2500 23.7 330 22.11 1 CB00008
M7 37 139.0 165.0 LA 305- S 2500 23.7 75 18.01 1 CB00008
M7 45 165.0 200.0 LA 305- S/SP1 2000 24.3 24.3 12.15 1 CB00008
M8 55 200.0 264.0 LA 305- S/SP1 2000 24.3 113 20.00 1 CB00008
M8 75 264.0 330.0 LA 305- S/SP1 2000 23.7 42.2 15.18 1 CB00008
M8 90 330.0 ? LA 305- S/SP1 2000 24.3 24.3 12.15 1 CB00008
400V P/kW Ict/A Ivt/A Current sensor R1 R2 Rtot N adapter board
M4 0.75 2.5 3.5 LA 55- P/SP1 2000 162 12000 159.84 5 CB00005
M4 1.1 3.5 4.5 LA 55- P/SP1 2000 158 1500 142.94 4 CB00005
M4 1.5 4.5 6.5 LA 55- P/SP1 2000 113 6650 111.11 4 CB00005
M4 2.2 6.5 8.0 LA 55- P/SP1 2000 100 330 76.74 4 CB00005
M4 3 8.0 10.0 LA 55- P/SP1 2000 86.6 2210 83.33 3 CB00005
M4 4 10.0 13.0 LA 55- P/SP1 2000 68.1 3320 66.73 3 CB00005
M4 5.5 13.0 18.0 LA 55- P/SP1 2000 100 330 76.74 2 CB00005
M5 7.5 18.0 24.0 LA 55- P/SP1 2000 113 6650 111.11 1 CB00006
M5 11 24.0 32.0 LA 55- P/SP1 2000 86.6 2210 83.33 1 CB00006
M5 15 32.0 42.0 LA 100 P 2000 68.1 768 62.55 1 CB00009
M6 18.5 42.0 48.0 LA 205- S 2000 48.7 2150 47.62 1 CB00007
M6 22 48.0 60.0 LA 205- S 2000 42.2 3320 41.67 1 CB00007
M6 30 60.0 75.0 LA 205- S 2000 42.2 158 33.30 1 CB00007
M6 37 75.0 90.0 LA 205- S 2000 27.4 1000 26.67 1 CB00007
M6 45 90.0 110.0 LA 205- S 2000 27.4 118 22.24 1 CB00007
M7 55 110 150.0 LA 305- S 2500 23.7 549 22.72 1 CB00008
M7 75 150 180.0 LA 305- S 2500 16.9 1210 16.67 1 CB00008
M7 90 180 210.0 LA 305- S/SP1 2000 12.7 88.7 11.11 1 CB00008
M8 110 210 270.0 LA 305- S 2500 27.4 182 23.81 1 CB00008
M8 132 270 325.0 LA 305- S 2500 18.7 1820 18.51 1 CB00008
M8 160 325 410.0 LA 305- S/SP1 2000 12.7 402 12.31 1 CB00008
M9 200 410 510.0 LA 305- S 2500 18.7 825 18.29 1 CB00008
M9 250 510 580.0 LA 305- S/SP1 2000 12.7 158 11.76 1 CB00008
M10 315 600 75.0 LA 305- S 2500 16.9 1210 16.67 1 CB00008
M10 400 750 840.0 LA 305- S/SP1 2000 12.7 66.5 10.66 1 CB00008
