Vacon CX Service Manual

APPENDIXES Service Manual M4 - M10
11.7.2002 Page 146
13.5 Cross reference list for Extender boards
Expander / Extender Cross Reference
ORIGINAL Layout version
NEW CB00019B CB00019C CB00119B CB00119C CB00119D CB00119E CB00119F CB00119G CB00119H CB00119K
Expander CB00019B X X a a a a a a a a
Expander CB00019C X a a a a a a a a
Extender CB00119B Xaaaaaaa
Extender CB00119C X X a a a a a
Extender CB00119D X X a a a a a
Extender CB00119E X a a a a
Extender CB00119F X a a a
Extender CB00119G X X X
Extender CB00119H X X X
Extender CB00119K X X X
It is recommended to change all (CB00019/CB00119) boards instead of mixing different versions
Note! Layout versions I and J skipped
a: possible to replace if all extender/expander boards are changed to same version (CB00019/CB00119)
X: interchangeable
