Vacon CX Service Manual

APPENDIXES Service Manual M4 - M10
11.7.2002 Page 145
SEMIKRON: R38, R41, R39, R42, Identifiers on the power board
R62, R65, R63, R66,
R86, R89 R87, R90
690V Gate Res Semikron Power Gate Resistance
Frame P (kW) IGBT-module ohm Brake IGBT-module Total R R parallel
M5 2,2 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 3 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 4 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 5,5 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 7,5 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 11 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 15 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 18,5 SKM75GB173D 22R SKD100GAL173D 22R 33R+100R+220R
M5 22 SKM100GB173D 10R SKD100GAL173D 22R 33R+100R+220R
M6 30 SKM100GB173D 10R SKM200GAL173D 22R 33R+100R+220R
M6 37 SKM150GB173D 5R6 SKM200GAL173D 22R 33R+100R+220R
M6 45 SKM150GB173D 5R6 SKM200GAL173D 22R 33R+100R+220R
M6 55 SKM200GB173D 4R7 SKM200GAL173D 22R 33R+100R+220R
M6 75 SKM200GB173D 4R7 SKM200GAL173D 22R 33R+100R+220R
M8 90 SKM150GB173D 5R6 2*SKM200GAL173D 22R 33R+100R+220R
M8 110 SKM150GB173D 5R6 2*SKM200GAL173D 22R 33R+100R+220R
M8 132 SKM200GB173D 4R7 2*SKM200GAL173D 22R 33R+100R+220R
M9 160 SKM150GB173D 5R6 3*SKM200GAL173D 22R 33R+100R+220R
M9 200 SKM200GB173D 4R7 3*SKM200GAL173D 22R 33R+100R+220R
M10 250 SKM200GB173D 4R7 4*SKM200GAL173D 22R 33R+100R+220R
M10 315 SKM200GB173D 4R7 4*SKM200GAL173D 22R 33R+100R+220R
