APPENDIXES Service Manual M4 - M10
11.7.2002 Page 142
13.4 Gate resistors
SEMIKRON R38, R41,
R39, R42, Identifiers on the power board
R62, R65,
R63, R66,
R86, R89 R87, R90
200V Gate Res
Gate Resistance
Frame P (kW) Bridge/IGBT-module ohm Module with brake Total R R parallel
M4 1,5 SKM 60 GD 062 DL 18R SKM40GDL123D 47R 47R
M4 2,2 SKM 60 GD 062 DL 18R SKM40GDL123D 47R 47R
M4 3 SKM 60 GD 062 DL 18R SKM40GDL123D 47R 47R
M5 4 SKM 60 GD 062 DL 18R SKD100GAL123D 47R 47R
M5 5,5 SKM 100 GD 062 DL 22R SKD100GAL123D 17R 47R+100R
M5 7,5 SKM 100 GD 062 DL 22R SKD100GAL123D 17R 47R+100R
M6 11 SKM 200 GD 062 DK 15R SKM195GAL123D 17R 47R+100R
M6 15 SKM 200 GD 062 DK 15R SKM195GAL123D 17R 47R+100R
M6 18,5 SKM 200 GD 062 DK 15R SKM195GAL123D 17R 47R+100R
M6 22 SKM 200 GD 062 DK 15R SKM195GAL123D 17R 47R+100R
M7 30 SKM 200 GB 062 D 10R 2*SKM195GAL123D 17R 47R+100R
M7 37 SKM 200 GB 062 D 10R 2*SKM195GAL123D 17R 47R+100R
M7 45 SKM 400 GB 062 D 4R7 2*SKM195GAL123D 17R 47R+100R
M8 55 SKM 400 GB 062 D 4R7 2*2*SKM195GAL123D 17R 47R+100R
M8 75 SKM 400 GB 062 D 4R7 2*2*SKM195GAL123D 17R 47R+100R
M8 90 SKM 400 GB 062 D 4R7 2*2*SKM195GAL123D 17R 47R+100R
