Vacon CX Service Manual

APPENDIXES Service Manual M4 - M10
11.7.2002 Page 143
SEMIKRON R38, R41, R39, R42, Identifiers on the power board
R62, R65, R63, R66,
R86, R89 R87, R90
400V/500V Gate R Gate Resistance
Frame P (kW) Bridge/IGBT-module ohm Brake IGBT-module Total R R parallel
M4 0,75 SKM22GD123D 47R SKM40GDL123D 47R 47R
M4 1,1 SKM22GD123D 47R SKM40GDL123D 47R 47R
M4 1,5 SKM22GD123D 47R SKM40GDL123D 47R 47R
M4 2,2 SKM22GD123D 47R SKM40GDL123D 47R 47R
M4 3 SKM22GD123D 47R SKM40GDL123D 47R 47R
M4 4 SKM22GD123D 47R SKM40GDL123D 47R 47R
M4 5,5 SKM40GD123D 47R SKM40GDL123D 47R 47R
M5 7,5 SKM75GB123D 22R SKD100GAL123D 17R 47R+100R
M5 11 SKM75GB123D 22R SKD100GAL123D 17R 47R+100R
M5 15 SKM100GB123D 15R SKD100GAL123D 17R 47R+100R
M6 18,5 SKM150GB123D 6R8 SKM195GAL123D 17R 47R+100R
M6 22 SKM150GB123D 6R8 SKM195GAL123D 17R 47R+100R
M6 30 SKM150GB123D 6R8 SKM195GAL123D 17R 47R+100R
M6 37,5 SKM200GB123D 5R6 SKM195GAL123D 17R 47R+100R
M6 45 SKM200GB123D 5R6 SKM195GAL123D 17R 47R+100R
M7 55 SKM300GB123D 4R7 2*SKM195GAL123D 17R 47R+100R
M7 75 SKM300GB123D 4R7 2*SKM195GAL123D 17R 47R+100R
M7 90 SKM400GB123D 3R9 2*SKM195GAL123D 17R 47R+100R
M8 110 SKM200GB123D 5R6* 2*2*SKM195GAL123D 17R 47R+100R
M8 132 SKM300GB123D 4R7* 2*2*SKM195GAL123D 17R 47R+100R
M8 160 SKM400GB123D 3R9* 2*2*SKM195GAL123D 17R 47R+100R
M9 200 SKM300GB123D 4R7* 3*2*SKM195GAL123D 17R 47R+100R
M9 250 SKM400GB123D 3R9* 3*2*SKM195GAL123D 17R 47R+100R
M10 315 SKM300GB123D 4R7* 4*2*SKM195GAL123D 17R 47R+100R
M10 400 SKM400GB123D 3R9* 4*2*SKM195GAL123D 17R 47R+100R
*= Single resistor version replaced with double resistor in beginning of year 1999
NOTE! Check that all gate resistor values are equal on every power board for M8-M10
SEMIKRON R38, R41, R39, R42, Identifiers on the power board
R62, R65, R63, R66,
R86, R89 R87, R90
400V/500V Gate R Gate Resistance
Frame P (kW) Bridge/IGBT-module ohm Brake IGBT-module Total R R parallel
M8 110 SKM200GB123D 8R2 18R2 2*2*SKM195GAL123D 17R 47R+100R
M8 132 SKM300GB123D 6R8 15R 2*2*SKM195GAL123D 17R 47R+100R
M8 160 SKM400GB123D 6R8 10R 2*2*SKM195GAL123D 17R 47R+100R
M9 200 SKM300GB123D 6R8 15R 3*2*SKM195GAL123D 17R 47R+100R
M9 250 SKM400GB123D 6R8 10R 3*2*SKM195GAL123D 17R 47R+100R
M10 315 SKM300GB123D 6R8 15R 4*2*SKM195GAL123D 17R 47R+100R
M10 400 SKM400GB123D 6R8 10R 4*2*SKM195GAL123D 17R 47R+100R
NOTE! Check that all gate resistor values are equal on every power board for M8-M10
