APPENDIXES Service Manual M4 - M10
11.7.2002 Page 144
TOSHIBA R38, R41, R39, R42, Identifiers on the power board
R62, R65, R63, R66,
R86, R89 R87, R90
400/500V Gate Res Gate Resistance
Frame P (kW) Bridge/IGBT-module ohm ohm Brake IGBT-module Total R R parallel
M4 2,2 MG15Q6ES42 220R 220R MG25Q1BS11 17R 47R+100R
M4 3 MG25Q6ES42 100R 100R MG25Q1BS11 17R 47R+100R
M4 4 MG25Q6ES42 100R 100R MG25Q1BS11 17R 47R+100R
M4 5,5
M5 7,5 MG50Q2YS40 47R 47R MG50Q1BS11 17R 47R+100R
M5 11 MG75Q2YS40 33R 33R MG75Q1BS11 17R 47R+100R
M5 15 MG75Q2YS40 33R 33R MG75Q1BS11 17R 47R+100R
M6 18,5 MG100Q2YS42 27R 15R 2*MG75Q1BS11 17R 47R+100R
M6 22 MG100Q2YS42 27R 15R 2*MG75Q1BS11 17R 47R+100R
M6 30 MG200Q2YS40 22R 10R 2*MG75Q1BS11 17R 47R+100R
M6 37,5 MG200Q2YS40 22R 10R 2*MG75Q1BS11 17R 47R+100R
M6 45 MG200Q2YS40 22R 10R 2*MG75Q1BS11 17R 47R+100R
M7 55 MG300Q2YS40 12R 10R MG300Q1US11 17R 47R+100R
M7 75 MG300Q2YS40 12R 10R MG300Q1US11 17R 47R+100R
M7 90 MG300Q2YS40 12R 10R MG300Q1US11 17R 47R+100R
M8 110
MG300Q2YS40 12R 10R 2*MG300Q1US11 17R 47R+100R
M8 132
MG300Q2YS40 12R 10R 2*MG300Q1US11 17R 47R+100R
M8 160
MG300Q2YS40 12R 10R 2*MG300Q1US11 17R 47R+100R
M9 200
MG300Q2YS40 12R 10R 3*MG300Q1US11 17R 47R+100R
M9 250
MG300Q2YS40 12R 10R 3*MG300Q1US11 17R 47R+100R
M10 315
MG300Q2YS40 12R 10R 4*MG300Q1US11 17R 47R+100R
M10 400
MG300Q2YS40 12R 10R 4*MG300Q1US11 17R 47R+100R
NOTE! 90kW or with 1:2500 current sensors: Always control board CB00023 or CB00061 with jumper X8 on
160kW or 250kW or 400kW or with 1:2500 current sensors:
Expander board CB0 0019, add 5k6 top of the resistor R52 or with Extender CB00119 cut R120 off
