APPENDIXES Service Manual M4 - M10
11.7.2002 Page 137
13.2.2 Construction M5
ITEM TYPE SCREW TORQUE FINAL
IGBT (mounting) SKM50GB123D M5*12 3,5Nm
IGBT (terminals) SKM50GB123D M5*10 3Nm
IGBT (mounting) SKM75GB123D M5*10 3,5Nm
IGBT (terminals) SKM75GB123D M5*10 3Nm
IGBT (mounting) SKM100GB123D M5*12 3Nm
IGBT (mounting) MG50Q2YS40 M5*12 3Nm
IGBT (terminals) MG50Q2YS40 3Nm
IGBT (mounting) MG75Q2YS40 M5*10 3Nm
IGBT (terminals) MG75Q2YS40 3Nm
Rectifier (mounting) SKD30/16 M4*12 1,75Nm
Rectifier (terminals) SKD30/16 M4*8 1,5Nm
Rectifier (mounting) SKD62/16 3Nm
Rectifier (terminals) SKD62/16 3Nm
Rectifier (mounting) SKD82/16 M5*12 3Nm
Rectifier (terminals) SKD82/16 M5*12 3Nm
Heatsink to chassis Aluminum M5*12 3Nm
Capacitor terminals All types M5*12 3Nm
Capacitor fastening All types M12 10Nm
Discharging resistor M3*8 1,5Nm
PCboard Power/Control board M3*8 1Nm
PC board Adapter board M4*8 1Nm
Panel bracket M3*8 1Nm
Terminals Power M6 2Nm
Mechanics M4*8 3Nm
