Vacon CX Service Manual

APPENDIXES Service Manual M4 - M10
11.7.2002 Page 138
13.2.3 Construction M6
ITEM TYPE SCREW TORQUE FINAL
IGBT (mounting) SKM100GB173D M6*16 3Nm
IGBT (terminals) SKM100GB173D M6*12 4Nm
IGBT (mounting) SKM150GB123D M6*16 4Nm
IGBT (terminals) SKM150GB123D M6*12 5Nm
IGBT (mounting) SKM150GB173D M6*16 4Nm
IGBT (terminals) SKM150GB173D M6*12 5Nm
IGBT (mounting) SKM195GAL123D M6*16 3Nm
IGBT (terminals) SKM195GAL123D M5*12 3Nm
IGBT (mounting) SKM200GAL173D M5*16 4Nm
IGBT (terminals) SKM200GAL173D M5*12 5Nm
IGBT (mounting) SKM200GB123D M6*16 4Nm
IGBT (terminals) SKM200GB123D M6*12 5Nm
IGBT (mounting) SKM200GB173D M6*16 4Nm
IGBT (terminals) SKM200GB173D M6*12 5Nm
IGBT (mounting) SKM200GD062DK M6*16 4Nm
IGBT (terminals) SKM200GD062DK M6*12 5Nm
IGBT (mounting) MG100Q2YS42 3Nm
IGBT (terminals) MG100Q2YS42 3Nm
IGBT (mounting) MG150Q2YS40 3Nm
IGBT (terminals) MG150Q2YS40 3Nm
IGBT (mounting) MG200Q2YS40 3Nm
IGBT (terminals) MG200Q2YS40 3Nm
Rectifier (mounting) SKD110 - 160 M6*16 3Nm
Rectifier (terminals) SKD110 - 160 M6*16 4Nm
Rectifier (mounting) SKD82 M5*12 3Nm
Rectifier (terminals) SKD82 M5*12 3Nm
Rectifier (mounting) SKKH57 M5*12 4Nm
Rectifier (terminals) SKKH57 M5*12 4Nm
Rectifier (mounting) SKKH72 M5*12 4Nm
Rectifier (terminals) SKKH72 M5*12 4Nm
Capacitor terminals 2200uf M5*12 2Nm
Capacitor terminals 3300uf M6*12 4Nm
Capacitor fastening All types M12 7,5Nm
Discharging resistor To bus bar M4*8 1Nm
Discharging resistor To frame M3*8 1Nm
PC board Power/Control board M3*8 1Nm
PC board Adapter board M4*8 2Nm
Panel bracket M3*8 1Nm
Terminals Power (KE33) 4Nm
Terminals Power (KE45) 10Nm
Contactor terminals Power terminals 5Nm
Contactor terminals Auxiliary terminals 2Nm
Current transducer To chassis M4*8 2Nm
Heatsink to chassis Aluminum M5*12 3Nm
Mechanics M4*8 2Nm
