Vacon CX Service Manual

APPENDIXES Service Manual M4 - M10
11.7.2002 Page 141
500V P/kW Ict/A Ivt/A Current sensor R1 R2 Rtot pc. adapter board
M4 0,75 2,5 3,0 LA 55- P/SP1 2000
162 12000
159,84 5 CB00005
M4 1,1 3 3,5 LA 55- P/SP1 2000
158 1500
142,94 4 CB00005
M4 1,5 3,5 5,0 LA 55- P/SP1 2000
113 6650
111,11 4 CB00005
M4 2,2 5,0 6,0 LA 55- P/SP1 2000
100 330
76,74 4 CB00005
M4 3 6,0 8,0 LA 55- P/SP1 2000
86,6 2210
83,33 3 CB00005
M4 4 8,0 11,0 LA 55- P/SP1 2000
68,1 3320
66,73 3 CB00005
M4 5,5 11,0 15,0 LA 55- P/SP1 2000
100 330
76,74 2 CB00005
M5 7,5 15,0 21,0 LA 55- P/SP1 2000
113 6650
111,11 1 CB00006
M5 11 21,0 27,0 LA 55- P/SP1 2000
86,6 2210
83,33 1 CB00006
M5 15 27,0 34,0 LA 100 P 2000 68,1 768 62,55 1 CB00009
M6 18,5 34,0 40,0 LA 205- S 2000 48,7 2150 47,62 1 CB00007
M6 22 40,0 52,0 LA 205- S 2000
42,2 3320
41,67 1 CB00007
M6 30 52,0 65,0 LA 205- S 2000
42,2 158
33,30 1 CB00007
M6 37 65,0 77,0 LA 205- S 2000 27,4 1000 26,67 1 CB00007
M6 45 77,0 96,0 LA 205- S 2000
27,4 118
22,24 1 CB00007
M7 55 96 125,0 LA 305- S 2500
23,7 549
22,72 1 CB00008
M7 75 125 160,0 LA 305- S 2500 16,9 1210 16,67 1 CB00008
M7 90 160 180,0 LA 305- S/SP1 2000
12,7 88,7
11,11 1 CB00008
M8 110 180 220,0 LA 305- S 2500
27,4 182
23,81 1 CB00008
M8 132 220 260,0 LA 305- S 2500 18,7 1820 18,51 1 CB00008
M8 160 260 320,0 LA 305- S/SP1 2000
12,7 402
12,31 1 CB00008
M9 200 320 400,0 LA 305- S 2500
18,7 825
18,29 1 CB00008
M9 250 400 460,0 LA 305- S/SP1 2000 12,7 158 11,76 1 CB00008
M10 315 480 600,0 LA 305- S 2500
16,9 1210
16,67 1 CB00008
M10 400 600 672,0 LA 305- S/SP1 2000 12,7 66,5 10,66 1 CB00008
690V P/kW Ict/A Ivt/A Current sensor R1 R2 Rtot N adapter board
M5 2,2 3,5 4,5
LA 55- P/SP1 2000
158,0 1500,0
142,94 4 CB00006
M5 3,0 4,5 5,5
LA 55- P/SP1 2000
113,0 6810,0
111,16 4 CB00006
M5 4,0 5,5 7,5
LA 55- P/SP1 2000
127,0 2740,0
121,37 3 CB00006
M5 5,5 7,5 10,0
LA 55- P/SP1 2000
158,0 205,0
89,23 3 CB00006
M5 7,5 10,0 14,0
LA 55- P/SP1 2000
158,0 274,0
100,21 2 CB00006
M5 11,0 14,0 19,0
LA 55- P/SP1 2000
158,0 1820,0
145,38 1 CB00006
M5 15,0 19,0 23,0
LA 55- P/SP1 2000
110,0 1820,0
103,73 1 CB00006
M5 18,5 23,0 26,0
LA 55- P/SP1 2000
113,0 412,0
88,68 1 CB00006
M5 22,0 26,0 35,0
LA 101- P 2000
100,0 330,0
76,74 1 CB00007
M6 30,0 35,0 42,0
LA 205- S 2000
59,0 1500,0 56,77 1 CB00007
M6 37,0 42,0 52,0
LA 205- S 2000
48,7 2740,0
47,85 1 CB00007
M6 45,0 11,0 62,0
LA 205- S 2000
48,7 187,0
38,64 1 CB00007
M6 55,0 62,0 85,0
LA 205- S 2000
35,7 330,0 32,21 1 CB00007
M6 75,0 85,0 100,0
LA 205- S 2000
23,7 6650,0
23,62 1 CB00007
M8 90,0 100,0 122,0
LA 305- S 2500
59,0 324,0
49,91 1 CB00008
M8 110,0 122,0 145,0
LA 305- S 2500
42,2 1330,0 40,90 1 CB00008
M8 132,0 145,0 185,0
LA 305- S 2500
42,2 187,0
34,43 1 CB00008
M9 160,0 185,0 222,0
LA 305- S 2500
48,7 243,0
40,57 1 CB00008
M9 200,0 222,0 287,0
LA 305- S 2500
48,7 110,0 33,76 1 CB00008
M10 250,0 287,0 325,0
LA 305- S 2500
35,7 1500,0
34,87 1 CB00008
M10 315,0 325,0 390,0
LA 305
-
S 2500
42,2 113,0 30,73 1 CB00008
