vacon • 10 Receipt of delivery
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
3.2 Type designation code for the LCL filter
LCL filters has two versions of cooling fan power supply, one without the integrated DC/DC power
supply and one with it. The LCL filter is characterized without the integrated DC/DC power supply
by letter A and with the integrated DC/DC power supply by letter B in version column, Figure 2.
Figure 2. Type designation code for the LCL filters
VACON LCL FILTERS FOR AFE - TYPE CODE
VACON LCL AAAA V A 0 R 0 1 1 T
LCL
Product range
LCL = LCL filter for AFE
0261 5
AAAA
0460 5
Nominal current (low overload)
1300 5
eg. 0460 = 460 A, 1300 = 130 A, etc.
0170 6
0325 6
1030 6
V
Voltage class
5 = 380-500 VAC
6 = 525-690 VAC
A
Version (hardware)
A = DC fan without DC/DC power supply
B = DC fan with integrated DC/DC power supply
0
Enclosure class:
0 = IP00
R
Reserve
0
Reserve
1
Reserve
1
Cooling fan type
1 = DC fan
T
Manufacturer
T = Trafotek
