vacon • 38 Active Front End (AFE)
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
4.12 Active Front End unit – Circuit breaker selection
The Active Front End can also be protected by a circuit-breaker. The recommended types of circuit-
breakers are shown in Table 18. If a circuit-breaker from another manufacturer is used, it must be
equivalent to the circuit-breakers shown. Further information on the circuit-breakers shown is
available from the manufacturer. Circuit-breakers do not provide the same level of protection as
fuses. A circuit-breaker can be used without a main contactor. In this case, the Active Front End unit
controls the circuit-breaker instead of the contactor. The circuit-breakers shown are suitable for
equipment rated at 380 V–500 V or 525 V–690 V.
Table 18. Circuit breaker for Vacon NXA
Type T5H400FF3LS
FI9
T5H400FF3LS
MOE230V/T4-5
UVRC230V/T4-5
ES-6/T5
AUX-C3+1/T4-5
PB100/T4-5-3P
AUX-SA1-S51+1/T4-5
MCCB
Motor
Undervoltage rel. (cabled)
Spreaded ext. term. incl. PB100
Aux./alarm cont. (cabled)
Phase separators for upper/lower
terminals
S51 NC
1SDA054349R1
1SDA054897R1
1SDA054891R1
1SDA055038R1
1SDA054911R1
1SDA054970R1
1SDA064518R1
Type T5H630FF3LS
FI10
T5H630FF3LS
MOE230V/T4-5
UVRC230V/T4-5
ES-6/T5
AUX-C3+1/T4-5
PB100/T4-5-3P
AUX-SA1-S51+1/T4-5
MCCB
Motor
Undervoltage rel. (cabled)
Spreaded ext. term. incl. PB100
Aux./alarm cont. (cabled)
Phase separators for upper/lower
terminals
S51 NC
1SDA054412R1
1SDA054897R1
1SDA054891R1
1SDA055038R1
1SDA054911R1
1SDA054970R1
1SDA064518R1
Type T7S16FF3PR231LS
FI13
Spring chargin motor 220...250 V
AC/DC
AUX 2Q 400 V AC
SOR 220…240 V AC/DC
T7S16FF3PR231LS
UVR 220…240 V AC/DC
SCR 220..240 V AC/DC
AUX-RTC 250 V AC/DC
Trip reset 200-240 V AC/DC
AUX-SA 1 S51 T7-T7M
SPRING CHARGING MOTOR
AUX. CONTACT
SHUNT OPENING RELEASE
MOULDED CASE CIRCUIT BREAKER
UNDER VOLTAGE RELAY
SHUNT CLOSING RELEASE
READY TO CLOSE
TRIP RESET UNIT
AUX-SA 1 S51 T7-T7M
1SDA062116R1
1SDA062102R1
1SDA063548R1
1SDA063010R1
1SDA063552R1
1SDA063550R1
1SDA062109R1
1SDA062119R1
1SDA063553R1
