4.11.3.2 DC fuses
NOTE! All fuses are flush-end type. If some other type is needed, please contact Vacon.
Table 16. Ferraz Shawmut DC fuse selection, mains voltage 640–1100 Vdc
Module DC fuses
Type Code Frame
Ferraz Shawmut
type [aR]*
U
N
[V]
I
N
[A]
Size Q'ty
AFE
NXA_0170 6 FI9 PC71UD13C400TF 1250 400 1 2
NXA_0325 6 FI10 PC73UD13C630TF 1250 630 3 2
NXA_1030 6 FI13 PC84UD11C20CTQ 1100 2000 84 2
Table 17. Bussman DC fuse selection, mains voltage 640–1100 Vdc
Module DC fuses
Type Code Frame
Bussman
type [aR]*
U
N
[V]
I
N
[A]
Size Q'ty
AFE
NXA_0170 6 FI9 170M4926 1250 400 1GKN/75 2
NXA_0325 6 FI10 170M8507 1250 700 3GKN/75 2
NXA_1030 6 FI13 170M8510 1100 1000 3GKN/75 3x2
