Active Front End (AFE) vacon • 21
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
4
4.2 Active Front End Unit block diagram
Figure 9. NXA block diagram
B+
B-
U/T1
V/T2
W/T3
RS-232
11170.emf
Power Module
Control Module Keypad
Control
Driver
Measure-
ments
Power
supply
Fan
ASIC
IGBT
bridge
I/O
slot E
I/O
slot D
I/O
slot C
I/O
slot A
I/O
slot B
