Vacon NX Active Front End User Manual

4
vacon • 34 Active Front End (AFE)
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
4.9 Active Front End unit – Dimensions
NOTE! More detailed dimensions can be found Appendix 73, Appendix 74 and Appendix 75.
4.10 LCL filter – Dimensions
NOTE! Weight is different for 500 V/690 V other dimensions are same for both voltage classes.
NOTE! More detailed dimensions can be found Appendix 76 and Appendix 77.
Table 8. The NXA unit dimensions
Module Module Dimension
Type Frame Height [mm] Width [mm] Depth [mm] Weight [kg]
AFE
FI9 1030 239 372 67
FI10 1032 239 552 100
FI13 1032 708 553 306
Table 9. LCL filter dimensions
Module Module Dimension
Type Frame Height [mm] Width [mm] Depth [mm] Weight [kg]
LCL
FI9 1775 291 515 241/245
FI10 1775 291 515 263/304
FI13 1442 494 525 477/473
