Performance Characteristics
Technical Specifications
ForceTriad User’s Guide 9-3
Operating Parameters
Transport and Storage
Internal Memory
Ambient temperature
range
+10° C to +40° C
Relative humidity 30% to 75% non-condensing
Atmospheric pressure 700 millibars to 1060 millibars
Warm-up time If transported or stored at temperatures outside the
operating temperature range, allow one hour for the
energy platform to reach room temperature before
use.
Ambient temperature
range
-30° C to +65° C
Relative humidity 0% to 90% (non-condensing)
Atmospheric pressure 500 millibars to 1060 millibars
Duration of storage The ForceTriad energy platform may be stored
indefinitely. If the energy platform is stored for over
one year, the memory battery must be replaced.
Nonvolatile, battery-
backed RAM
Battery type: Lithium
Battery life: 120 mAh
Storage capacity 256 KB
