Output Power vs. Resistance Graphs
Technical Specifications
ForceTriad User’s Guide 9-17
Output Power vs. Resistance Graphs
Monopolar Graphs
Pure Cut
Output power versus impedance
for Pure cut power
Output power versus power setting
for Pure cut power
Peak voltage versus power setting
for Pure cut power
0
50
100
150
200
250
300
350
0 1000 2000 3000 4000 5000
50%
100%
Load Impedance (ohms)
Output power (watts)
0
50
100
150
200
250
300
0 100 200 300
Cut, Output Power
vs . S et t ing @
300ohm
Power Setting
Output power (watts)
0
100
200
300
400
500
600
700
800
900
1000
0 100 200 300
Open Circuit Cut
Peak Voltage vs.
Power setting
Power Setting
Peak Voltage
