Output Power vs. Resistance Graphs
9-18 ForceTriad User’s Guide
Blend
Output power versus impedance
for Blend power
Output power versus power
setting for Blend power
Peak voltage versus power
setting for Blend power
0
50
100
150
200
250
0 1000 2000 3000 4000 5000
50%
100%
Load Impedance (ohms)
Output power (watts)
0
20
40
60
80
100
120
140
160
180
200
0 50 100 150 200
Blend Output Power
vs . S et t i ng @
300ohm
Output power (watts)
Power Setting
0
200
400
600
800
1000
1200
1400
1600
0 50 100 150 200
Open Circuit Blend
Peak Voltage vs.
Power Setting
Power Setting
Peak Voltage
