Output Power vs. Resistance Graphs
Technical Specifications
ForceTriad User’s Guide 9-21
Valleylab
Output power versus impedance
for Valleylab power
Output power versus power setting
for Valleylab power
Peak voltage versus power setting
for Valleylab power
0
50
100
150
200
250
0 1000 2000 3000 4000
50%
100%
Load Impedance (ohms)
Output power (watts)
0
20
40
60
80
100
120
140
160
180
200
0 50 100 150 200
Hemostasis w/
Division Output
power vs. Power
Setting @ 300ohm
Power Setting
Output power (watts)
0
500
1000
1500
2000
2500
0 50 100 150 200
Open Circuit
Valleylab Mode
Peak Voltage vs.
Power Setting
Power Setting
Peak Voltage
