Valor L2 SERIES User Manual

34
Flashing Kit
Co-linear terminal kits
Terminal Cap
Dimensions with co-linear adapter
Dimensions shown are with Valor 1156CLA co-linear
adapter.
Installation
For installation of the adapter to the appliance, see the
instructions supplied with the 1156CLA.
Co-linear Venting
Example of co-linear terminal confi gurations
9-3/8”
11-11/16”
3” exhaust
collar
1-1/2”
4” exhaust
collar adapter
FRONT REAR
1156CLA Co-Linear Vent Adapter
4”
8-5/8”
52”
32-3/8”
18-1/8”
3” intake
4” exhaust collar
on the centerline
QUALIFIED
INSTALLER
