Valor L2 SERIES User Manual

25
20.1/8”
43”
57.3/4”
1/2” thick non-combustible
cement board required above,
on each side and below
engine opening (NOT supplied)
NOTE: Height of cavity may be
affected by vent configuration
- see page 26
Between underside
of header and bottom
of firebox
No hearth required.
If using a hearth,
see page 22.
NOTE: This unit requires a
solid platform to support it.
Combustible framing allowed
beneath fireplace. When the
appliance is installed directly
on carpeting, tile or other
combustible material other
than wood flooring, the
appliance shall be installed
on a metal or wood panel
extending the full width
and recessed depth of the
appliance
8
8”
NON-COMBUSTIBLE MATERIALS ONLY
READ INSTRUCTIONS
MATÉRIAUX INCOMBUSTIBLES SEULEMENT
CONSULTEZ LE GUIDE D’INSTALLATION
NON-CO
MBUSTI
BLE MA
TERIAL
S ONLY
READ I
READ I
NSTRUC
NSTRUC
TIONS
TIONS
MATÉRIMATÉRI
AUX INAUX IN
COMBUSCOMBUS
TIBLESTIBLES
SEULESEULE
MENTMENT
CONSULCONSUL
TEZ LETEZ LE
GUIDEGUIDE
D’INSD’INS
TALLATTALLAT
IONION
Min. 60” (1524 mm)
50” (1270 mm)
Min. 44-1/2” (1130 mm)
Min.
20-1/2”
(521 mm)
14-3/4”
(375 mm)
Min.
9-1/4”
(235 mm)
Min. 5”
(127 mm)
Min. 5”
(127 mm)
Flush with bottom of unit;
add extra cement board
if overlapping framing.
Joints preferred at corners
to prevent cracking
Minimum coverage area of non-combustible cement board.
Any wall nish applied to shaded area must be non-combustible.
Linear 1700 replace outline
(including stand-os)
Non-combustible
cement board
required
thickness:
1/2 inch (13 mm)
NON-COMBUSTIBLE MATERIALS ONLY
READ INSTRUCTIONS
MATÉRIAUX INCOMBUSTIBLES SEULEMEN
T
CONSULTEZ LE GUIDE D’INSTALLATION
23.
27
Framing Requirements
Framing Dimensions
Minimum Cement Board Dimensions
QUALIFIED
INSTALLER
