Valor L2 SERIES User Manual

60
Spare Parts
Code Description
Part
Number
1 Heat shield 4003049
2 45 degrees fl anged elbow 0945M
3 Elbow gasket 4002999
4 Top stand-offs (2) 4002985
5 Restrictor plate 4003017
6 Take-off cover (2) 4003046
7 Battery slder assembly 4003644
8 LH Window latch assembly 4002770
9 RH Window latch assembly 4002766
10 Top panel support 4002963
11 Cable hole cover 4003038
13 Window assembly 4003567
14 Black metal platform 4004138AH
15a Burner module assembly NG 4003747
15b Burner module assembly LPG 4003748
16 Burner 4003589
18 Platform supports (2) 4002908
19 Pilot shield 4003018AH
20a Pilot assembly NG 4000727
20b Pilot assembly LPG 4000728
21 Thermocouple 4000061
22a Pilot injector NG #51 4000735
22b Pilot injector LPG #30 4000736
23 Pilot tube 4000732
24 Pilot hood 2-fl ame 4000730
25 Extended nut 4001855
26 Electrode 4001856
27 Burner location bracket 4002902
28a Injector elbow NG 82-1000 4003985
28b Injector elbow LPG 92-380 4004145
29 Air shutter 4002907
30 Burner gasket (air shutter) 4002906
31 Gasket silicone 620C016
32 Burner module plate 4002775
33 Gaskets module plate, long (2) 3000400
34 Gaskets module plate, short (2) 3000399
35 Pilot sealing plate 4002910
36 Valve to elbow pipe assembly 4003749
37a GV60 valve assembly NG 4003986
37b GV60 valve assembly LPG 4003987
38 Thermocouple interrupter 4001037
39 Pipe s/s fl ex 4000345
Code Description
Part
Number
40 Handset wall holder 9000008
41 Handset G6R H3T5-ZV (BJ) 4001910
42 Receiver G6R-R3AM-ZV (CP) 4001911
43 Wire harness GV60 4001187
44 Cable interrupter 500 mm 4002096
45 Ignition cable sleeve 530 mm 4002244
46 Ignition cable 500 mm 4001039
47 Wall switch kit 1265WSK
48 Battery box w/cable 1500 mm 4002249
49 Liner panels - complete set
Fluted Black Liners 1715FBL
Refl ective Glass Liners 1725RGL
50 Rear panel
Fluted Black - centre panel only 4003955
Glass (3) 4004275
50a Rear panel
Fluted Black - sides (2) 4003727
Glass -
51 LH side panel
Black 4003071
Glass 4004273
52 RH side panel
Black 4003072
Glass 4004274
53 Top panel
Black (2) 4003728
Black (2) 4003728
54 Murano Glass Fire 1710DGM
55a Glass panel 401 x 66 mm 4003746A
55b Glass panel 401 x 82 mm 4003746B
55c Glass panel 119.5 x 46 mm 4003746C
55d Glass panel 119.5 x 78.5 mm 4003746D
55e Glass panel 384.5 x 66 mm (2) 4003746E
55f Glass panel 384.5 x 82 mm (2) 4003746F
56 Classic 1/4” black fi re glass 4002931
57 Premium 1/4” Azuria fi re glass 4002932
59 Driftwook Kit 1705DWK
60 Rear log 4002938
61 LH end log 4002965
62 LH front log 4002967
63 Center cross log 4003721
64 RH rear log 4003928
