Valor L2 SERIES User Manual

43
6. Place rear panel’s centre section on the ledge
behind the tabs, slide it to the right so that its
stepped edge fi ts into the stepped edge of the rear
panel’s right section.
7. Place the left side panel against the left
wall of the fi rebox.
8. Tighten the side panel anchors on each
side of the fi rebox
9. Place the remaining rear panel’s section behind
the left side panel and fi t its stepped edge to the
stepped edge of the rear panel’s center section.
10. Carefully lift, slide and position top panel on to left
side and rear panel.
NOTE: If gapping occurs between each section
of the rear panel, a lift tab located on each end of
ledge can be bent by hand to close the gap.
Installation
QUALIFIED
INSTALLER
