VAMP 50 User Manual

2.2 Local panel operations 2 Local panel user interface Operation and confi
g
uration
A list of the local main menu
Main
menu
Number
of
menus
Description
ANSI
code
Note
1 Interactive mimic display 1
5
Double size measurements
defined by the user
1
1
Title screen with device name,
time and firmware version.
Meas 7 Measurements
Imax 8
Time stamped min & max of
currents
Mont 17
Maximum values of the last 31
days and the last twelve
months
Evnt 2 Events
DR 3 Disturbance recorder 2
Runh 1
Running hour counter. Active
time of a selected digital input
and time stamps of the latest
start and stop.
TIMR 6 Day and week timers
DI 4
Digital inputs including virtual
inputs
DO 3
Digital outputs (relays) and
output matrix
ExtAI External analogue inputs 3
ExDI External digital inputs 3
ExDO External digital outputs 3
Prot 18
Protection counters, combined
overcurrent status, protection
status, protection enabling, cold
load and inrush detectionIf2>
and block matrix
I> 12 1st overcurrent stage 50/51 4
I>> 11 2nd overcurrent stage 50/51 4
I>>> 11 3rd overcurrent stage 50/51 4
I< 11 Undercurrent stage 37 4
I2/I1> 11 Broken conductor prot. Stage 46R 4
I2> 10 Unbalance stage 46 4
I2>> 10
Phase reversal / incorrect phase
sequence stage
47 4
Ist> 10 Stall protection stage 48 4
N> 11 Frequent start 66 4
T> 3 Thermal overload stage 49 4
Io> 12 1st earth fault stage 50N/51N 4
Io>> 11 2nd earth fault stage 50N/51N 4
Io>>> 11 3rd earth fault stage 50N/51N 4
Io>>>> 11 4th earth fault stage 50N/51N 4
Prg1 11 1st programmable stage 4
12
VAMP 24h support phone +358 (0)20 753 3264 VM50.EN004
