VAMP 50 User Manual

Technical description 4 Measurement functions 4.3 Harmonics and Total Harmonic
Distortion
(
THD
)
VM50.EN004 VAMP 24h support phone +358 (0)20 753 3264
139
4.3. Harmonics and Total Harmonic
Distortion (THD)
The device calculates the THDs as percentage of the base
frequency for currents and voltages.
The device calculates the harmonics from the 2
nd
to the 15
th
of
phase currents and voltages. (The 17
th
harmonic component
will also be shown partly in the value of the 15
th
harmonic
component. This is due to the nature of digital sampling.)
The harmonic distortion is calculated using equation
1
15
2
2
h
h
THD
i
i



, where
h
1
= Fundamental value
h
2...15
= Harmonics
Example
h
1
= 100 A
h
3
= 10 A
h
7
= 3 A
h
11
= 8 A
%2.13
100
8310
222


THD
For reference the RMS value is:
ARMS 9.1008310100
2222

Another way to calculate THD is to use the RMS value as
reference instead of the fundamental frequency value. In the
example above the result would then be 13.0 %.
4.4. Demand values
The relay calculates average i.e. demand values of phase
currents I
L1
, I
L2
, I
L3
and power values S, P and Q. The demand
time is configurable from 10 minutes to 30 minutes with
parameter "Demand time".
