VAMP 50 User Manual

Technical description 6 Communication 6.2 Communication protocols
VM50.EN004 VAMP 24h support phone +358 (0)20 753 3264
175
Parameters
Parameter Value Unit Description Note
Mode
Cont
Reqst
Profile selection
Continuous mode
Request mode
Set
bit/s 2400 bps
Communication speed
from the main CPU to the
Profibus converter. (The
actual Profibus bit rate is
automatically set by the
Profibus master and can
be up to 12 Mbit/s.)
Emode
Channel
(Limit60)
(NoLimit)
Event numbering style.
Use this for new
installations.
(The other modes are for
compatibility with old
systems.)
(Set)
InBuf bytes
Size of Profibus master's
Rx buffer. (data to the
master)
1) 3)
OutBuf bytes
Size of Profibus master's
Tx buffer. (data from the
master)
2) 3)
Addr
1  247
This address has to be
unique within the
Profibus network system.
Set
Conv

VE
Converter type
No converter recognized
Converter type "VE" is
recognized
4)
Set = An editable parameter (password needed)
Clr = Clearing to zero is possible
1) In continuous mode the size depends of the biggest configured data offset
of a data item to be send to the master. In request mode the size is 8 bytes.
2) In continuous mode the size depends of the biggest configured data offset
of a data to be read from the master. In request mode the size is 8 bytes.
3) When configuring the Profibus master system, the lengths of these
buffers are needed. The device calculates the lengths according the Profibus
data and profile configuration and the values define the in/out module to be
configured for the Profibus master.
4) If the value is "", Profibus protocol has not been selected or the device
has not restarted after protocol change or there is a communication problem
between the main CPU and the Profibus ASIC.
