2.2 Local panel operations
2 Local panel user interface
Operation and configuration
14
VAMP 24h support phone +358 (0)20 753 3264
VM59.EN001
Main
menu
Number
of
menus
Description
ANSI
code
Note
Io>>
3
2nd earth fault stage
50N/51N
4
Io>>>
3
3rd earth fault stage
50N/51N
4
Io>>>>
3
4th earth fault stage
50N/51N
4
Io >
6
1
st
directional earth fault stage
67N
4
Io >>
7
2
nd
directional earth fault stage
67N
4
Uo>
3
1st residual overvoltage stage
59N
4
Uo>>
3
2nd residual overvoltage stage
59N
4
Prg1
3
1st programmable stage
4
Prg2
3
2nd programmable stage
4
Prg3
3
3rd programmable stage
4
Prg4
3
4th programmable stage
4
Prg5
3
5th programmable stage
4
Prg6
3
6th programmable stage
4
Prg7
3
7th programmable stage
4
Prg8
3
8th programmable stage
4
CBFP
3
Circuit breaker failure
protection
50BF
4
CBWE
5
Circuit breaker wearing
supervision
4
CTSV
1
CT supervisor
4
ArcI>
11
Optional arc protection stage
for phase-to-phase faults and
delayed light signal.
50ARC
4
ArcIo>
10
Optional arc protection stage
for earth faults. Current input
= I01
50NARC
4
AR
4
Auto-reclose
79
OBJ
11
Object definitions
5
Lgic
2
Status and counters of user’s
logic
1
CONF
9
Device setup, scaling etc.
6
Bus
11
Serial port and protocol
configuration
7
OPT
1
Option cards
Diag
9
Device selfdiagnosis
Notes
1
Configuration is done with VAMPSET
2
Recording files are read with VAMPSET
3
The menu is visible only if protocol "ExternalIO" is selected for one of
the serial ports. Serial ports are configured in menu "Bus".
4
The menu is visible only if the stage is enabled.
5
Objects are circuit breakers, disconnectors etc.
6
There are two extra menus, which are visible only if the access level
"operator" or "configurator" has been opened with the corresponding
password.
7
Detailed protocol configuration is done with VAMPSET.
