Operation and configuration
2 Local panel user interface
2.2 Local panel operations
VM59.EN001
VAMP 24h support phone +358 (0)20 753 3264
13
Main menu
The general menu structure is shown in Figure 2.2.1-2. The
menu is dependent on the user’s configuration and the options
according the order code. For example only the enabled
protection stages will appear in the menu.
A list of the local main menu
Main
menu
Number
of
menus
Description
ANSI
code
Note
1
Interactive mimic display
1
5
Double size measurements
defined by the user
1
1
Title screen with device name,
time and firmware version.
Meas
14
Measurements
Imax
5
Time stamped min & max of
currents
Mont
17
Maximum values of the last 31
days and the last twelve
months
Evnt
2
Events
DR
3
Disturbance recorder
2
Runh
2
Running hour counter. Active
time of a selected digital input
and time stamps of the latest
start and stop.
TIMR
6
Day and week timers
DI
5
Digital inputs including virtual
inputs
DO
4
Digital outputs (relays) and
output matrix
AO
2
Visible only when AO card
installed
Prot
9
Protection counters, combined
overcurrent status, protection
status, protection enabling, cold
load and inrush detectionIf2>
and block matrix
MSTAT
1
Motor status
LdI>
4
1
st
line differential stage
87L
4
LdI>>
4
2
nd
line differential stage
87L
4
I>
5
1st overcurrent stage
50/51
4
I>>
3
2nd overcurrent stage
50/51
4
I>>>
3
3rd overcurrent stage
50/51
4
I2>
3
Current unbalance stage
46
4
T>
3
Thermal overload stage
49
4
If2>
3
Second harmonic O/C stage
51F2
4
If5>
3
Fifth harmonic O/C stage
51F5
4
Io>
5
1st earth fault stage
50N/51N
4
