Technical description
5 Control functions
5.8 Auto-reclose function (79)
VM59.EN001
VAMP 24h support phone +358 (0)20 753 3264
153
DI to block AR setting
This setting is useful with an external synchro-check device.
This setting only affects re-closing the CB. Re-closing can be
blocked with a digital input, virtual input or virtual output.
When the blocking input is active, CB won‟t be closed until the
blocking input becomes inactive again. When blocking becomes
inactive the CB will be controlled close immediately.
Setting parameters of AR function:
Parameter
Value
Unit
Default
Description
ARena
ARon; ARoff
-
ARon
Enabling/disabling the
autoreclose
Block
None,
any digital
input,
virtual input
or virtual
output
-
-
The digital input for block
information. This can be used,
for example, for Synchrocheck.
AR_DI
None,
any digital
input,
virtual input
or virtual
output
-
-
The digital input for toggling
the ARena parameter
AR2grp
ARon; ARoff
-
ARon
Enabling/disabling the
autoreclose for group 2
ReclT
0.02 … 300.00
s
10.00
Reclaim time setting. This is
common for all the shots.
ARreq
On; Off
-
Off
AR request event
ShotS
On; Off
-
Off
AR shot start event
ARlock
On; Off
-
Off
AR locked event
CritAr
On; Off
-
Off
AR critical signal event
ARrun
On; Off
-
Off
AR running event
FinTrp
On; Off
-
Off
AR final trip event
ReqEnd
On; Off
-
Off
AR end of request event
ShtEnd
On; Off
-
Off
AR end of shot event
CriEnd
On; Off
-
Off
AR end of critical signal event
ARUnl
On; Off
-
Off
AR release event
ARStop
On; Off
-
Off
AR stopped event
FTrEnd
On; Off
-
Off
AR final trip ready event
ARon
On; Off
-
Off
AR enabled event
ARoff
On; Off
-
Off
AR disabled event
CRITri
On; Off
-
On
AR critical final trip on event
AR1Tri
On; Off
-
On
AR AR1 final trip on event
AR2Tri
On; Off
-
On
AR AR2 final trip on event
CRITri
On; Off
-
On
AR critical final trip off event
AR1Tri
On; Off
-
On
AR AR1 final trip off event
AR2Tri
On; Off
-
On
AR AR2 final trip off event
