2.12 Line differential protection
LdI> (87L)
2 Protection functions
Technical description
78
VAMP 24h support phone +358 (0)20 753 3264
VM59.EN001
Example 1:Normal situation from relay 1 point of view
Relay1: measured phase current I
L1
=1000A/0°.
Relay2: measured phase current I
L1
=300A/-180°.
CT scaling of relay1 is 1000A / 5A and nominal current is
1000A. CT scaling of relay2 is 1000A / 1A and the nominal
current is 300A. Relay2 sends primary current measurement
information to relay1 and relay1 swaps the angle of received
current by 180 degrees (relay2 phase current I
L1
=300A/-180° 
300A/0°).
In BIAS-calculation the measured current amplitude is divided
by the nominal primary current of both ends (might be
different like now).
Relay1: I
PRIMARY MEASURED
/ I
NOMINAL
= 1000A / 1000A = 1
Relay2: I
PRIMARY RECEIVED
/ I
NOMINAL REMOTE
= 300A / 300A = 1
Nd
II  00101
Example 2:Fault situation from relay 1 point of view
Relay1: measured phase current I
L1
=2400A/-30°.
Relay2: measured phase current I
L1
=2100A/-45°.
CT scaling of relay1 is 1000A / 5A and nominal current is
1000A. CT scaling of relay2 is 1000A / 1A and the nominal
current is 300A. Relay2 sends primary current measurement
information to relay1 and relay1 swaps the angle of received
current by 180 degrees (relay2 phase current I
L1
=2100A/-45° 
2100A/135°).
In BIAS-calculation the measured current amplitude is divided
by the nominal primary current of both ends (might be
different like now).
Relay1: I
PRIMARY MEASURED
/ I
NOMINAL
= 2400A / 1000A = 2.4
Relay2: I
PRIMARY RECEIVED
/ I
NOMINAL REMOTE
= 2100A / 300A = 7
Nd
II  37.91357354.2
Nb
II 

 1
2
11
Nb
II 

 7.4
2
74.2
