Vari Lite VL2402 - Troubleshooting Guide

VARI❋LITE® - VL2402™ WASH LUMINAIRE USER’S MANUAL
86 17-Sept-01 02.9671.0001 C
Troubleshooting Guide
If a problem is suspected, try recalibrating the luminaire to prompt an error message.
Refer to “Error Messages” on page 55 for more information. The chart below provides
possible causes and remedies for each message.
CAUTION: Some troubleshooting is included for reference only. Performing
remedies marked by gray areas will void product warranty. Refer to “Protecting Your
Warranty” on page 85.
Table A-1: VL2402 Troubleshooting Guide
Error Display Description Possible Cause and Remedy
B1M1
MAG
NoSn
Aux Board 1, Motor 1,
Magenta,
Sensor Not Found
Magenta power not connected,
motor not moving
- Connect Magenta motor power
at motor
Magenta sensor not connected
- Connect Magenta sensor
Magenta movement restricted or
impeded
- Remove obstruction
Magenta sensor is faulty
- Replace color sensor assembly
Aux Board 1 is faulty
Replace aux board
B1M1
MAG
SAct
Aux Board 1, Motor 1,
Magenta,
Sensor Always Active
Magenta power not connected and
Magenta aligned with sensor
- Connect Magenta power at
motor
B1M2
Dimm
NoSn
Aux Board 1, Motor 2,
Dimmer,
Sensor Not Found
Dimmer power not connected,
motor not moving
- Connect dimmer power at motor
Dimmer sensor not connected
- Connect dimmer sensor
Dimmer movement restricted or
impeded
- Remove obstruction
Dimmer sensor is faulty
- Replace dimmer sensor
assembly
Aux Board 1 is faulty
Replace aux board
