VARI❋LITE® - VL2402™ WASH LUMINAIRE USER’S MANUAL
62 17-Sept-01 02.9671.0001 C
Function Definitions
Each menu item is listed in the first column by its display abbreviation. The
abbreviations appear in alphabetical order.
Table 4-3: Menu Function Definitions
Display Definition Purpose
⇓⇓
Display Orientation Shows upside-down orientation (for hanging luminaires)
⇑⇑
Display Orientation Shows upright orientation.
8 Standard 8-bit Configures luminaire for operation in standard DMX 8-bit mode.
16 Standard 16-bit Configures luminaire for operation in standard DMX 16-bit mode.
10M 10 Minutes Sets Menu Display to automatically shut off after 10 minutes of non-use.
30s 30 Seconds Sets Menu Display to automatically shut off after 30 seconds of non-use.
5M 5 Minutes Sets Menu Display to automatically shut off after 5 minutes of non-use.
Addr Address Accesses functions for setting luminaire starting address in either Virtuoso
(VIRT) or DMX (DMX) controlled systems.
ALL All Motors Tests all internal motors.
Ambr Amber Specifies Amber for manual control (Man) or test Amber functions (Test).
Auto Auto Detect or
Auto Playback
Automatically detects required Menu Display orientation when selected (DDir) or
initiates automatic playback of a cue sequence at power-up (CUE).
Blue Blue Specifies Blue for manual control (Man) or tests Blue functions (Test).
BTim Beam Time Accepts timing value for beam time.
C ON On after Calibration Configures arc luminaire so that lamp will strike after calibration procedure is
complete.
Cal Re calibrate Re calibrates luminaire.
CFG System
Configuration
Accesses functions for setting lamp start up, pan/tilt, and Menu Display
configurations. Also accesses lamp information such as number of strikes, and
hours used, along with their respective reset function.
CWhl Color Wheel Specifies Color Wheel for manual control and test.
CMiX Color Mixer Tests color mixing mechanism.
CTim Color Time Sets color time. This applies to Blue, Amber, Magenta and Color Wheel.
Cue Cue Processing Accesses cue store, modify, delete, and playback commands.
cXX Cue Data Specifies cue number for display of current data value.
cXXX DMX Channel Specifies DMX channel for display of current data value.
DATA DMX Data Accesses function for displaying DMX data by channel number.
DDir Display Orientation Accesses option to orient Menu display for reading correctly in either hanging or
floor mounting installations.
Del Delete Cue Deletes cues by number. Cue number deleted is dependent on last cue ID in cue
list since this field is not editable.
DIFF Diffusion Specifies manual control of Diffusion (Man) or tests Diffusion functions (Test).
Dimm Dimmer Specifies dimmer mechanism for manual control (Man) or tests dimmer/strobe
functions (Test).
Dis Disable Disables a function.
DisP Display Illumination Accesses options for Menu Display on and off times.
DISP Display Test Tests all 14 segments in the Display.
