INSTALLATION : POWER AND DATA CABLING REQUIREMENTS
2
02.9671.0001 C 17-Sept-01 11
Power and Data Cabling Requirements
Power
The luminaire requires standard AC power distribution from 90-264 VAC, 50/60 Hz.
Four amps to twelve amps will be required depending on the AC supply voltage and
product model.
Depending on the application, the luminaire’s AC input cable may require a different
connector. If required, install a new connector meeting your requirements using the
following wire color code reference:
* International (Harmonized) Standard
WARNING: DO NOT connect to three-phase service in countries with 240 volt
power.
For single-phase power at 100 to 240 volts RMS:
For three-phase power at 208 volts RMS:
Wire* Connection
Green/Yellow AC Ground
Blue AC Neutral
Brown AC Line
Connection Pin
AC Neutral X
AC Line Y
Ground (Earth) G
Connection Pin
Phase 1 X
Phase 2 Y
Ground (Earth) G
X
Y
G
X
Y
G
