VARI❋LITE® - VL2402™ WASH LUMINAIRE USER’S MANUAL
98 17-Sept-01 02.9671.0001 C
Optical
Source
700 Watt Short-Arc Lamp, 5600°K, 80CRI
Reflector
Precision glass reflector with dichroic cold mirror coating.
Operational
Power Requirements
All VL2402 models are powered through standard AC power distribution and require
three amps to twelve amps depending on the AC supply voltage and product model.
All VL2402 models operate from 90-263 +/- 10% VAC, 50/60 Hz
Operational Temperature
-20° to 122°F (-29° to 50°C) *
Cooling
Forced air cooling.
Control
Compatible with the VARI❋LITE automated lighting system, featuring the Virtuoso™
console and Artisan® console families. Also compatible with a wide variety of
DMX512 consoles.
Mounting Position
The VL2402 wash luminaire can be mounted and operated in any orientation.
