DMX Modes
8-Bit and 16-Bit Modes
These tables assume a DMX start address of 1. When a different starting address is
used, this address becomes channel 1 function and other functions follow in sequence.
Standard 8-Bit (8) Standard 16-Bit (16)
Enhanced 8-Bit (E 8) Enhanced 16-Bit (E 16)-Default
Function DMX Channel Function DMX Channel
Dimmer 1 Dimmer 1
Pan 2 Pan 2 - 3
Tilt 3 Tilt 4 - 5
Blue 4 Blue 6
Amber 5 Amber 7
Magenta 6 Magenta 8
Color Wheel 7 Color Wheel 9
Diffusion 8 Diffusion 10
Strobe 9 Strobe 11
Control 10 Control 12
Function DMX Channel Function DMX Channel
Dimmer 1 Dimmer 1
Pan 2 Pan 2 - 3
Tilt 3 Tilt 4 - 5
Blue 4 Blue 6
Amber 5 Amber 7
Magenta 6 Magenta 8
Color Wheel 7 Color Wheel 9
Diffusion 8 Diffusion 10
Strobe 9 Strobe 11
Focus Timing 10 Focus Timing 12
Color Timing 11 Color Timing 13
Beam Timing 12 Beam Timing 14
Control 13 Control 15
