VARI❋LITE® - VL2402™ WASH LUMINAIRE USER’S MANUAL
70 17-Sept-01 02.9671.0001 C
Self Tests
Running Parameter Tests
The luminaire is capable of running self tests by using the TEST menu functions.
When running tests on multiple luminaires, a loopback connector is required at the
final luminaire in the link and a male termination connector is required at the “master”
luminaire. Refer to page 15 for more information regarding the construction of these
connectors.
For complete details and values for each test refer to “Diagnostic Tests” on page 72.
Note: After 10 seconds of inactivity, the menu display will change to the default state
showing the address.
Move Disable
The Move option has been added to the test menu. This allows for pan/tilt functions
to be disabled so that the luminaire can be placed in any position for testing without
movement occurring. In order to regain full control of the luminaire, Move will need
to be enabled after testing.
Note: When setting the Move option to disable, luminaires linked by a loopback
connector will have pan and tilt disabled for all the luminaires that are linked.
WARNING: Backcap and adjustment knobs will be HOT during lamp operation.
Wear gloves and/or use tools to prevent burns.
Lamp
The Lamp option has been added to the test menu. This option sets the lamp intensity
to 100% and will adjust the diffusion to produce a tight beam. See “Align Lamp for
Flat Field” on page 22 for instructions on lamp adjustment. Pan/Tilt are disabled while
using the Lamp option, and pan/tilt settings will be restored upon exit of the Lamp
feature.
Note: When setting the Lamp option on luminaires linked by a loopback connector,
pan and tilt will be disabled for all the luminaires that are linked.
To run tests:
1. Press [Menu].
2. Press [Up] / [Down] arrows until TEST appears. Press [Enter].
