MENU SYSTEM : OPERATION
4
02.9671.0001 C 17-Sept-01 55
Error Messages
If a problem occurs during luminaire calibration, at the end of the calibration sequence
the Menu Display will cycle through any applicable error message(s), one at a time
until the end of the list is reached. To review the error messages again, it will be
necessary to access them using the Status function. (Refer to “Troubleshooting” on
page 85 for a list of possible causes and remedies associated with the error messages.)
Access Error Messages:
1. Press [Menu].
2. Press [Up] / [Down] arrows until Fixt (Fixture) appears. Press [Enter].
3. Press [Up]/ [Down] arrows to access STAT. Press [Enter]. (Display will now
scroll through any error messages or display OK if no errors.)
Table 4-1: Error Messages
Display Message...
OK No Errors Found
B1M1 / MAG / NoSn Aux Board 1, Motor 1 / Magenta / Sensor Not Found
B1M1 / MAG / SAct Aux Board 1, Motor 1 / Magenta / Sensor Always Active
B1M2 / Dimm / NoSn Aux Board 1, Motor 2 / Dimmer / Sensor Not Found
B1M2 / Dimm / SAct Aux Board 1, Motor 2 / Dimmer / Sensor Always Active
B1M3 / CWhl / NoSn Aux Board 1, Motor 3 / Color Wheel / Sensor Not Found
B1M3 / CWhl / SAct Aux Board 1, Motor 3 / Color Wheel / Sensor Always Active
B2M1 / Blue / NoSn Aux Board 2, Motor 1 / Blue / Sensor Not Found
B2M1 / Blue / SAct Aux Board 2, Motor 1 / Blue / Sensor Always Active
B2M2 / Ambr / NoSn Aux Board 2, Motor 2 / Amber / Sensor Not Found
B2M2 / Ambr / SAct Aux Board 2, Motor 2 / Amber / Sensor Always Active
BRD1 / NO / COMM Aux Board 1 Communication Failure
BRD2 / NO / COMM Aux Board 2 Communication Failure
HEAD/ OVER/ TEMP Head Over Temperature
LAMP / STRK / FAIL Lamp Strike Failure
PAN / ENCR / FAIL Pan Encoder Failure
PAN / NO / SENS Pan Sensor Not Found
PAN / SENS / ACTV Pan Sensor Always Active
SRCH/FOR/BRD1 Attempting to communicate with Board 1
SRCH/FOR/BRD2 Attempting to communicate with Board 2
TILT / ENCR / FAIL Tilt Encoder Failure
