OPERATION : LUMINAIRE TIMING
3
02.9671.0001 C 17-Sept-01 41
Control Channel Functions
The following control actions must be accomplished with zero time transition or with
timing disabled. Discrete values must be used and not manual controls such as faders
or encoders.
To use control channel functions:
1. Select an action to be sent.
2. Set control channel value for desired action (for example, 84 for reset). Hold
value for 3 seconds.
Note: A numerical keypad is required for sending values. An encoder or fader does
not allow for a quick value change, which is required to affect the control functions.
3. Set control channel value to zero. (This must occur without any scaling
values. Action will be voided if other values are detected between action
value and zero.)
Note: The Snap control channel function takes place immediately, and does not
require the control value be set to zero after three seconds. For more information on
Snap functionality see “Snap Colors” on page 27.
Control
Channel
Function
Control Channel Value
% Value
For 3 Secs
or Greater
After
3 Secs
Display On 1 1-4 0
Snap On 9 20-25 N/A
Snap Off 13 30-35 N/A
Luminaire Reset 33 81 - 87 0
Lamp Off 66 165 - 171 0
Lamp On 99 249 - 255 0
