MENU SYSTEM : MAPPING
4
02.9671.0001 C 17-Sept-01 61
Note: A decimal to the right of a menu display readout indicates either a Virtuoso
address or that the page is 1 of 2. Refer to “Decimal Placement” on page 53.
Test (cont.)* Sens Sensors Pan EOT Sensor STST Sensor Test in
Progress
PASS
FAIL
Tilt EOT Sensor STST Sensor Test in
Progress
PASS
FAIL
Dimm Dimmer/Strobe EOT
Sensor
STST Sensor Test in
Progress
PASS
FAIL
CWhl Color Wheel EOT Sensor STST Sensor Test in
Progress
PASS
FAIL
Blue Blue EOT Sensor STST Sensor Test in
Progress
PASS
FAIL
Ambr Amber EOT Sensor STST Sensor Test in
Progress
PASS
FAIL
MAG Magenta EOT Sensor STST Sensor Test in
Progress
PASS
FAIL
DISP Display X.X.X.X. Ingites all 14 segments
of each of the 4 characters and
all 4 decimal points.
*Refer to
“Diagnostic Tests” on page 72
for more information.
Table 4-2: Menu System Functions (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
