VARI❋LITE® - VL2402™ WASH LUMINAIRE USER’S MANUAL
88 17-Sept-01 02.9671.0001 C
B2M2
Ambr
NoSn
Aux Board 2, Motor 2,
Amber,
Sensor Not Found
Amber power not connected, motor
not moving
- Connect Amber power at motor
Amber sensor not connected
- Connect Amber sensor
Amber movement restricted or
impeded
- Remove obstruction
Amber sensor is faulty
- Replace color sensor assembly
Aux Board 2 is faulty
Replace aux board
B2M2
Ambr
SAct
Aux Board 2, Motor 2,
Amber,
Sensor Always Active
Amber power not connected, and
amber aligned with sensor
- Connect Amber power at motors
BRD1
NO
COMM
Aux Board 1
Communication Failure
Aux input connector (J5) not
connected to either aux board
- Connect aux input connector (J5)
to either aux board
Jumper/bridge connector (J1)
between aux boards not connected
- Install jumper/bridge connector
(J1) between aux boards
BRD2
NO
COMM
Aux Board 2
Communication Failure
Aux input connector (J5) not
connected to either aux board
- Connect aux input connector (J5)
to either aux board
Jumper/bridge connector (J1)
between aux boards not connected
- Install jumper/bridge connector
(J1) between aux boards
LAMP
STRK
FAIL
Lamp Strike Failure Lamp failed to strike after repeated
attempts
- Replace lamp
PAN
ENCR
FAIL
Pan Encoder Failure Main board pan/tilt connector (J9)
disconnected
- Connect main board pan/tilt
connector (J9)
Pan motor disconnected
- Connect pan motor power
Encoder faulty
Replace pan end-of-travel/encoder
sensor assembly
Table A-1: VL2402 Troubleshooting Guide (Continued)
Error Display Description Possible Cause and Remedy
