MENU SYSTEM : MAPPING
4
02.9671.0001 C 17-Sept-01 59
Fixt STAT Status/Error Display Scrolls error messages *
or displays OK
Cal Recalibrate OK?
Modl Luminaire Model Type XXXX Model Type
LId Luminaire ID XXXX. Luminaire ID Number
(Page 1)
XXXX Luminaire ID
Number (Page 2)
Ver Version XX.XX. Version (Page 1) XX.XX Version
(Page 2)
FHrs Fixture Hours On XXXX Hours
Dnld Download Program to
Luminaires
OK? XXXX - # of Blocks
received
Man
Manual
Commands
Pan Pan Motor XXXX Data
Tilt Tilt Motor XXXX Data
Dimm Dimmer XXX Data
Strb Strobe XXX Data
CWhl Color Wheel XXX Data
Blue Blue XXX Data
Ambr Amber XXX Data
MAG Magenta XXX Data
DIFF Diffusion XXX Data
Time Timing Data ITim Dimmer/Intensity Time XXX.X Data
FTim Focus Time XXX.X Data
CTim Color Time XXX.X Data
BTim Beam Time XXX.X Data
Cue
Cue
Processing
FLTM Follow Time XXX.X Data
Stor Store Cue cXX Cue # to Store
(Not editable – given next cue
ID in list)
Mod Modify Cue cXX List of Cues
Del Delete Cue cXX Cue # to Delete
(Not editable – given last cue ID
in list)
PCue Play Cue cXX List of Cues
PSEQ Play Sequence Press [Enter] to start
Press [Menu] to stop
ScXX - Sequence,
Cue # currently
playing
DSEQ Delete Sequence OK?
SEQ
Sequence Playback Mode
ISEQ Individual Sequence
(default)
MSEQ Master Sequence
Auto Autoplay at Power-Up OFF
ON
* Refer to “Error Messages” on page 55.
Table 4-2: Menu System Functions (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
