Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
62 / 214
COPYRIGHT© 2020 VATECH.
3.5.2. Bright calibration: 4 points
1. Run the C:\VCaptureSW\Acquisition\CBCT\WidePANO\VACAP.exe file.
2. Click the Settings tab and make sure that the parameters under [BrightCalibration] are as
shown below and click the Save button if something is changed.
3. Click the Soft Calib tab.
4. When acquiring 4 point cal, the initial value is as follows and it is set according to the
standard by adjusting kVp.
Acquisition conditions
Half Scan
4 point 2 point
exposure
condition
kVp0 580 710
mA0 530 700
kVp1 920 830
mA1 950 900
5. Send [SPM_ARCT], [SPM_CSON], [SPM_FIPM_0001], [SPM_FISS_0001],
[SPM_FISM_0001], [SPM_COLM_0010] commands to the command window to set the CT
sensor and collimator.
To Next Page
