8. Setting up PC’s Environment Variables
vatech A9 (Model: PHT-30CSS) Installation Manual 99
8. Setting up PC’s Environment Variables
Disregard this section in case the PC system is supplied with
the equipment. (The environment variables of the PC have
already been set on the PC.)
8.1 Before Beginning
Ensure that the Emergency Stop Switch is in the OFF
position before starting with the InstallShield
installation.
DO NOT install the programs irrelevant to image
acquisition and view on the same PC. There may be
subtle conflicts between them, leading to the
malfunction.
The PC system supplied with the equipment is intended
to be used as an image acquisition only. To the PC
server for image management, it is strongly
recommended to use a different PC.
The programs related to the acquisition, viewing, and
man Insert the 3D viewer USB imputation of images
should be installed on the formatted PC, where no
other program(s) except the operating system (OS) is
present.
Before InstallShield installation, ensure that the video
card driver installed on the PC is the most up-to-date
version. To check this, go to the website of the graphics
card manufacturer.
Checking PC BIOS Settings
The PC is shipped, with its BIOS settings, as specified in Appendix D. Checking PC
BIOS Settings. Before proceeding to the next sections, check the BIOS status.
In case the BIOS settings have not been configured in advance, or the settings are
different, perform the following steps.
1. Reboot the PC and go to BIOS setting mode.
2. Set the variables as shown in the following table.
Enhanced Halt State (C1E)
When you update the BIOS settings, the “EnhancedHalt State (C1E)” option will
be displayed.
