6. Completing Miscellaneous Works
vatech A9 (Model: PHT-30CSS) Installation Manual 81
6.3 Installing the Switch Holders
Parts and
Accessory
UP / DOWN
Switch Holder
1 pc
(Part No. 33)
UP / DOWN
Switch
Optional - 1 pc
(Part No. 33)
Flat Head Screw
M3 x 8 – 3 pcs
Sticker (Part No. 33)
UP / DOWN Switch / Switch Holder
1. Choose a place where you want to install a UP/DOWN Switch Holder (You can
install the holder on either the left or right side of the equipment).
To Next Page
