10. Technical Specifications
vatech A9 (Model: PHT-30CSS) Installation Manual 131
English
10. Technical Specifications
10.1 Mechanical Specifications
Dimensions (unit = mm)
Item Description
Weight
Without
CEPH unit
92 kg (202.83 lbs. - without Base)
130 kg (286.60 lbs. – with Base)
With
CEPH unit
118 kg (260.15 lbs. - without Base)
156 kg (343.92 lbs. - with Base)
Total Height
Without
Base
Max. 1,698 mm (66.85”)
With
Base
Max. 1,716 mm (67.56”)
Dimensions
during operation
(Length x Width
x Height)
Without
CEPH unit
without Base:
772.0 (L) x 1,173.3 (W) x 1,698.0 (H) (mm)
30.39 (L) x 46.20 (W) x 66.85 (H) (inch)
with Base:
983.3 (L) x 1,173.3 (W) x 1,716.0 (H) (mm)
38.71 (L) x 46.20 (W) x 67.56(H) (inch)
With
CEPH unit
without Base:
1,873.5 (L) x 1,173.3 (W) x 1,698.0 (H) (mm)
73.76 (L) x 46.20 (W) x 66.85 (H) (inch)
with Base:
1,938.9 (L) x 1,173.3 (W) x 1,716.0 (H) (mm)
76.33 (L) x 46.20 (W) x 67.56(H) (inch)
Installation type
Base Stand/Wall Mount
(Default: Wall Mount type)
Packing Box Organization
Main Box, CEPH Box (Optional), Base Box
(Optional)
